Flame Retardant XLPE Insulated Power Cable is designed for power transmission and distribution systems rated up to 0.6/1kV. It adopts cross-linked polyethylene (XLPE) as insulation, providing superior electrical performance, high heat resistance, and excellent mechanical strength. The outer sheath is made of flame-retardant PVC or LSZH (Low Smoke Zero Halogen) material, effectively limiting flame spread and smoke emission in the event of fire. This cable is ideal for use in high-rise buildings, subways, tunnels, petrochemical plants, power stations, and other fire safety-critical areas.
[Conductor] → [XLPE Insulation] → [Core Assembly] → [Flame Retardant PVC/LSZH Sheath]
Cable Components
|
Component |
Material |
Features |
|
Conductor |
Annealed Copper or Aluminum |
Excellent conductivity and flexibility |
|
Insulation |
Cross-linked Polyethylene (XLPE) |
High dielectric strength and 90°C temperature resistance |
|
Core Identification |
Color or Number Marking |
Easy installation and maintenance |
|
Sheath |
Flame Retardant PVC or LSZH |
Low smoke, non-toxic, and flame-resistant |
Technical Parameters
|
Item |
Unit |
Parameter |
|
Rated Voltage |
V |
0.6/1kV |
|
Max. Operating Temperature |
°C |
90 |
|
Short-circuit Temperature (≤5s) |
°C |
250 |
|
Min. Bending Radius |
- |
≥12D (D = cable diameter) |
|
Flame Retardant Standard |
- |
IEC 60332 / GB/T 19666 |
|
Smoke Density |
- |
IEC 61034 |
|
Halogen Content |
- |
IEC 60754 (for LSZH type) |
Product Features
- Excellent flame retardant and self-extinguishing performance
- XLPE insulation provides superior thermal stability and aging resistance
- Optional LSZH material for low smoke and halogen-free requirements
- Compact structure, easy bending, and simple installation
- Outstanding electrical performance and long service life
Applications
- High-rise buildings, subways, tunnels, and public facilities
- Petrochemical plants, metallurgical, and energy industries
- Power plants, fire protection, and control systems
- Power supply lines requiring fire-retardant performance
Standards
- GB/T 12706 - Power Cables with XLPE Insulation Rated up to 1kV
- GB/T 19666 - General Rules for Flame-Retardant and Fire-Resistant Cables
- IEC 60332 - Tests on Electric Cables under Fire Conditions
- IEC 60502 - Power Cables with Extruded Insulation Rated up to 1kV
Typical Models
|
Model |
Name |
Characteristics |
|
YJV |
Copper Conductor XLPE Insulated PVC Sheathed Cable |
Standard flame-retardant type |
|
YJV22 |
Copper Conductor XLPE Insulated Steel Tape Armored PVC Sheathed Cable |
Enhanced mechanical protection |
|
YJV32 |
Copper Conductor XLPE Insulated Steel Wire Armored PVC Sheathed Cable |
Suitable for vertical installation |
|
YJV62 |
Copper Conductor XLPE Insulated LSZH Sheathed Cable |
Low smoke, halogen-free type |
|
YJVR |
Flexible Copper Conductor XLPE Insulated Flame Retardant Cable |
Flexible, ideal for mobile installations |
Product Advantages
- Complies with national and IEC flame-retardant standards
- High insulation resistance and stable current-carrying capacity
- Superior thermal endurance and long service life
- Environmentally friendly and low smoke emission
- Customizable design to meet various installation environments
FAQ
Q: What is an XLPE Fire Resistant Cable?
A: An XLPE Fire Resistant Cable is a power or control cable insulated with cross-linked polyethylene (XLPE) and designed to maintain circuit integrity during a fire.
Q: What are the main features of this cable?
A: It provides excellent fire resistance, high temperature endurance, low smoke emission, and halogen-free performance, ensuring safety in critical environments.
Q: Where is it commonly used?
A: It is widely used in power supply systems of high-rise buildings, tunnels, subways, hospitals, and emergency circuits where fire safety is essential.
Q: What standards does the cable comply with?
A: It can be manufactured according to IEC 60331, BS 6387, or other international fire-resistance standards.
Q: Can you customize cables according to customer requirements?
A: Yes. We offer customization for cable size, conductor structure, insulation material, sheath color, and printing details according to customer needs.
