Product Description

Compensating Cable for R Type Thermocouple is specially designed for connecting R-type thermocouples (Platinum-Rhodium/Platinum) to temperature measurement and control instruments. These cables use conductors made of special compensating alloys that accurately reproduce the thermoelectric characteristics of R-type thermocouples within the operating temperature range, ensuring precise temperature signal transmission.

Construction

Conductor: Solid or stranded compensating alloy wires corresponding to Platinum-Rhodium/Platinum thermoelectric properties.
Insulation: PVC, PTFE, FEP, or fiberglass depending on temperature and environmental requirements.
Shielding (Optional): Aluminum foil or tinned copper braid for EMI/RFI protection.
Outer Sheath: PVC, silicone rubber, or fiberglass braid – heat, oil, and chemical resistant.
Color Code: According to IEC 60584 or ANSI MC96.1 standards.

Technical Specifications

Item	Description
Thermocouple Type	R Type (PtRh–Pt)
Temperature Range	-20°C to +200°C (PVC), up to +400°C (FEP or fiberglass)
Rated Voltage	300V
Insulation Resistance	≥100 MΩ/km
Test Voltage	1.5 kV/1 min
Tolerance	±1.5°C or ±0.4% of reading
Standards	IEC 60584-3 / ANSI MC96.1
Sheath Options	PVC / PTFE / Silicone / Fiberglass

Type	Description
KX-GS-VVR	Precision-grade compensation cable specifically designed for K-type soft-core thermocouples, featuring PVC insulation and a double-layer PVC sheath structure, suitable for general-purpose applications.
KX-GS-VPVRR	K-Type Soft-Core Thermocouple Dedicated Precision-Grade Compensation Cable PVC Insulation, Twisted Copper Wire Braided Single-Layer Shielding, PVC Sheath, Universal Type
KX-GS-VPVPR	K-Type Soft-Core Thermocouple Dedicated Precision-Grade Compensation Cable PVC Insulation Twisted Copper Wire Braided Single-Layer and Overall Shielding PVC Sheath General Purpose
KX-GS-VVPR	PK-Type Soft-Core Thermocouple Compensation Cable, PVC Insulation, Twisted Copper Wire Braided Shield, PVC Sheath, Universal Type
KX-HS-FFR	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation and a dual-layer fluoroplastic sheath structure.
KX-HS-FP, FR	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, a single-layer shielding layer of twisted tinned copper wire braid, and a fluoroplastic outer sheath.
KX-HS-FPFPR	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, a single layer of twisted tinned copper wire braid with integral shielding, and an outer fluoroplastic sheath.
KX-HS-FFP₁R	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, a braided shield of twisted tinned copper wires, and a fluoroplastic outer sheath.
KX-HS-FV15R	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, twisted-pair construction, and an outer jacket of 105°C heat-resistant PVC.
KX-HS-FP₁V1R	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, single-layer shielding with twisted tinned copper wire braid, and a 105°C heat-resistant PVC jacket.
KX-HS-FP₁V1₀P.R	Precision-Grade High-Temperature Compensation Cable for K-Type Soft-Core Thermocouples Fluoroplastic insulation, twisted tinned copper wire braid with individual and overall shielding 105°C heat-resistant PVC jacket
KX-HS-FV1PR	Precision-grade high-temperature compensation cable specifically designed for K-type soft-core thermocouples, featuring fluoroplastic insulation, a braided shield of twisted tinned copper wires, and a 105°C heat-resistant PVC jacket.
